Abstract

Robotic throwing enables fast object transport and extends a robot’s reachable workspace beyond traditional pick-and-place. While prehensile (grasp-based) throwing works well for graspable items, non-prehensile (grasp-free) throwing is better suited for large, heavy, and/or deformable objects. Existing approaches rely on model-based optimization with simplified contact models (e.g., dynamic grasping) and low-dimensional trajectory parameterizations, which limit solution quality and reachable workspace. We propose a reinforcement learning approach that additionally leverages sliding and rolling contact modes and directly optimizes joint-space trajectories without ana- lytical contact models or custom parameterizations. The Markov Decision Process (MDP) is formulated as a dynamical system that evolves the robot’s joint state conditioned on the throwing target, object model, and initial configuration. Joint-jerk trajectories are planned offline at a low control rate and upsampled into smooth, high-rate velocity commands for deployment. For sim-to-real transfer, we minimize the robot-dynamics gap through minimum- jerk system identification and train uncertainty-aware policies to mitigate object-modeling errors, particularly sensitivity to dynamic friction. In simulation, the policy achieves 99% success across thousands of configurations and generalizes to unseen objects. Sensitivity analysis shows robustness to mass uncertainty but high sensitivity to dynamic friction, consistent with the sliding-based release mechanism. Deployed zero-shot on a UR5e operating near its physical limits (5 m/s end-effector velocity), our method throws diverse objects—including heavy (790 g) and large (20 × 20 × 28 cm) items—to targets up to 350 cm distance or 180 cm elevation, achieving a 97% real-world success rate.
